National Transonic Facility (NTF) Test Section Geometry

The test section geometry for the NTF has been released.

Details are documented in the 2025 AIAA AVIATION paper paper and presentation as PowerPoint and pdf.

Zip File: NTF_highspeedleg_definition_v1p9.zip (June 26, 2025)
See the change log summary below

Facility Virtual Tour


The single zip file includes twelve parts in three formats (.stp, .iges, and .x_t). The CAD of each component of the geometry is released independently with no common assembly. Some images below show the 12 individual parts, seen in gray. Some assemblies are presented in color, though these assemblies are not included in the CAD release.

Image 1
Circuit and released geometry
Image 2
NTF_Additional_Obstructions_2023_10_02
Image 3
NTF_arc_sector_aft_fixed
Image 4
NTF_Arc_Sector_CameraPod_2023_10_02
Image 5
NTF_arc_sector_fwd_rotational_0deg
Image 6
NTF_Arc_Sector_Rotational_Axis_Cylinder_2023_10_02
Image 7
NTF_Arc_Sector_Straight_Sting_0deg_2023_10_02
Image 8
NTF_Contraction_TestSection_Diffusor_2023_10_02
Image 9
NTF_Diffusor_2023_10_02
Image 10
NTF_Diffusor_Constant_Cross_Section_Extension_2023_10_02
Image 11
NTF_Inlet_Contraction_2023_10_02
Image 12
NTF_TestSection_Baseline_in_Plenum_2023_10_02
Image 13
NTF_USS_Sting_noRotation_2024_08_15
Image 14
All parts with unique coloring
Image 15
Isometric View 1
Image 16
Isometric View 2
Image 17
Isometric View 3
Image 18
Isometric View 4
Image 19
Side View 1
Image 20
Side View 2
Image 21
Side View 3
Image 22
Interior View 1
Image 23
Interior View 2
Image 24
Interior View 3
Image 25
Interior View 4
Image 26
Interior View 5
Image 27
Interior View 6
Image 28
Interior View 7
Image 29
Interior View 8



The twelve parts are named as follows:

Change Log

A high level overview of version increments is shown here. More details can be found in the README files in the zip file.

Version 1.9 June 26, 2025 Updated and enhanced coordinate transformations for the 2.7% full span, 5.2% semispan, and 2.7% semispan models and enhanced documentation
Version 1.8 May 16, 2025 Incorrectly updated the distance from the 5.2% scale CRM fuselage centerline to the tunnel wall
Version 1.7 April 28, 2025 A small clamshell part was previously missing from the X_T and IGES versions of NTF_USS_Sting_noRotation_2024_08_15, added; also added CRM coordinate transformations
Version 1.6 October 11, 2024 Replaced NTF_Arc_Sector_wStingHub_Sym_0deg_2023_10_02 with 2 new parts: NTF_arc_sector_aft_fixed and NTF_arc_sector_fwd_rotational_0deg
Version 1.5 August 26, 2024 Improved upper-swept strut modeling (replaced NTF_Arc_Sector_TopLoadingSting_0deg_2023_10_02 with NTF_USS_Sting_noRotation_2024_08_15
Version 1.4 October 4, 2023 Created a combined NTF_Contraction_TestSection_Diffusor_2023_10_02 part


Email brent.w.pomeroy@nasa.gov to be added to the announcement email list.
